Linecard W12003   Radial Varistor Explosion Proof Size 30,0x26,0x14,5mm
PDF +Part-No. Varistor Voltage Maximum Voltage Clamping Voltage (max.) Maximum Energy Rated Power Maximum Peak Current Capacitance reference (1KHz)
10/1000µS 1 time 2 times
(V)  (AC) (DC) (VP) (Ip) (J) (J) 2ms (W) (A) (A) (pf)
W12003-820
82 50 65 135 100 40 56 1,0 10000 7000 7500
W12003-101 100 60 85 165 100 50 70 1,0 10000 7000 6500
W12003-121 120 75 100 200 100 60 85 1,0 10000 7000 5500
W12003-151 150 95 125 250 100 75 106 1,0 10000 7000 4500
W12003-201 200 130 170 340 100 100 140 1,0 10000 7000 1700
W12003-221 220 140 180 360 100 110 155 1,0 10000 7000 1600
W12003-241 240 150 200 395 100 120 168 1,0 10000 7000 1500
W12003-271 270 175 225 455 100 135 190 1,0 10000 7000 1300
W12003-331 330 210 270 545 100 160 228 1,0 10000 7000 1100
W12003-361
360 230 300 595 100 180 255 1,0 10000 7000 1100
W12003-391 390 250 320 650 100 195 275 1,0 10000 7000 1100
W12003-431 430 275 350 710 100 215 303 1,0 10000 7000 1000
W12003-471 470 300 385 775 100 250 350 1,0 10000 7000 900
W12003-511 510 320 410 845 100 273 382 1,0 10000 7000 800
W12003-561 560 350 460 910 100 273 382 1,0 10000 7000 700
W12003-621 620 385 505 1025 100 273 382 1,0 10000 7000 700
W12003-681 680 420 560 1120 100 273 382 1,0 10000 7000 650
W12003-751 750 460 615 1240 100 300 420 1,0 10000 7000 600
W12003-781 780 485 640 1290 100 312 440 1,0 10000 7000 560
W12003-821 820 510 670 1355 100 325 460 1,0 10000 7000 530
