LINECARD R17002 GLASS FUSE 5,0x20mm FAST ACTING

PDF Datasheet

Ampere Rating

Voltage

Nominal Resistance Cold Ohms

Voltage Drop (mV) Max.

Nominal Melting I²t A²Sec.

R17002-0063

0,063 A

250V

10,2400

1500

0,000794

R17002-0080

0,080 A

250V

8,7160

1300

0,001280

R17002-0100

0,10 A

250V

4,7670

1200

0,001800

R17002-0125

0,125 A

250V

4,4410

1200

0,002810

R17002-0160

0,16 A

250V

2,8420

1100

0,005370

R17002-0200

0,20 A

250V

1,8930

1000

0,016000

R17002-0250

0,25 A

250V

1,1630

800

0,025000

R17002-0315

0,315 A

250V

0,4090

500

0,039700

R17002-0400

0,40 A

250V

0,2950

300

0,080100

R17002-0500

0,50 A

250V

0,2400

250

0,125000

R17002-0630

0,63 A

250V

0,1950

230

0,198000

R17002-0800

0,80 A

250V

0,1280

200

0,768000

R17002-1000

1,00 A

250V

0,0920

180

1,300000

R17002-1250

1,25 A

250V

0,0730

170

1,875000

R17002-1600

1,60 A

250V

0,0570

160

3,328000

R17002-2000

2,00 A

250V

0,0430

160

5,600000

R17002-2500

2,50 A

250V

0,0300

160

8,750000

R17002-3150

3,15 A

250V

0,0240

150

14,880000

R17002-4000

4,00 A

250V

0,0180

130

24,000000

R17002-5000

5,00 A

250V

0,0130

130

40,000000

R17002-6300

6,30 A

250V

0,0100

130

67,470000

R17002-8000

8,00 A

250V

0,0087

130

140,800000

R17002-1001

10,00 A

250V

0,0063

150

300,000000
