5mm Bullet LED  Mono Color   Serie M13E5xxx
Item-No. + Size Viewing Color Lens Type Typical Value Color  If/ mA
Forward  Luminious Wave Length   Temper-
Data Sheet ( Unit: mm ) Angle Voltage Intensity nm or ature
( V ) ( mcd ) (Coordinates) ( K )
M13E5001
  5.0 6 Blue Clear 3.5 ~ 4.3 1250 ~ 1600 470 --- 20 M13E5001
M13E5002
  5.0 10 Blue Green Clear 3.7 ~ 4.3 2000 ~ 4000 505 --- 20 M13E5002
M13E5003
  5.0 6 Green Clear 3.7 ~ 4.3 2500 ~ 4000 525 --- 20 M13E5003
M13E5004
  5.0 12 Green Clear 2.1 ~ 2.4 250 ~ 385 571 --- 20 M13E5004
M13E5005
  5.0 6 Green Clear 2.1 ~ 2.4 400 ~ 630 571 --- 20 M13E5005
M13E5006
  5.0 6 Yellow Clear 2.0 ~ 2.4 1160 ~ 3100 589 --- 20 M13E5006
M13E5007
  5.0 6 Yellow Clear 2.0 ~ 2.4 5810 ~ 9300 589 --- 20 M13E5007
M13E5008
  5.0 6 Yellow Clear 2.0 ~ 2.4 8120 ~ 10560 589 --- 20 M13E5008
M13E5009
  5.0 6 Orange Clear 2.0 ~ 2.4 1240 ~ 3290 615 --- 20 M13E5009
M13E5010
  5.0 6 Orange Clear 2.0 ~ 2.4 6180 ~ 10290 615 --- 20 M13E5010
M13E5011
  5.0 6 Orange Clear 2.0 ~ 2.4 9040 ~ 11760 615 --- 20 M13E5011
M13E5012
  5.0 6 Red Clear 2.0 ~ 2.4 950 ~ 2460 624 --- 20 M13E5012
M13E5013
  5.0 6 Red Clear 2.0 ~ 2.4 4420 ~ 7580 624 --- 20 M13E5013
M13E5014
  5.0 6 Red Clear 2.0 ~ 2.4 4790 ~ 8200 624 --- 20 M13E5014
M13E5015
  5.0 6 Red Clear 2.0 ~ 2.4 970 ~ 1680 639 --- 20 M13E5015
M13E5016
  5.0 6 Red Clear 2.0 ~ 2.4 2590 ~ 3490 639 --- 20 M13E5016
M13E5017
  5.0 6 Red Clear 2.0 ~ 2.4 2800 ~ 3780 639 --- 20 M13E5017
M13E5018
  5.0 13 White Clear 3.6 ~ 4.0 3000 ~ 5000 --- --- 20 M13E5018
M13E5019
  5.0 8 Blue Clear 3.1 ~3.6 14400~16000 470 --- 20 M13E5019
M13E5020   5.0 8 Pure Green Clear 3.1 ~3.6 30000~36000 525 --- 20 M13E5020
M13E5021   5.0 8 Violett Clear 3.1 ~3.6 220~300 405 --- 20 M13E5021
M13E5022   5.0 8 Red Clear 2.1 ~2.6 12000~15000 625 --- 20 M13E5022
M13E5023   5.0 8 Yellow Clear 2.1 ~2.6 12000~15000 590 --- 20 M13E5023
M13E5024   5.0 8 Orange Clear 2.1 ~2.6 12000~15000 605 --- 20 M13E5024
M13E5025   5.0 8 Red Clear 2.1 ~2.6 36000~40000 625 --- 20 M13E5025
M13E5026   5.0 8 Yellow Clear 2.1 ~2.6 36000~40000 590 --- 20 M13E5026
M13E5027   5.0 8 Orange Clear 2.1 ~2.6 36000~40000 605 --- 20 M13E5027
M13E5028   5.0 8 Red Clear 2.1 ~2.6 50000~60000 625 --- 20 M13E5028
M13E5029   5.0 8 Yellow Clear 2.1 ~2.6 50000~60000 590 --- 20 M13E5029
M13E5030   5.0 8 Orange Clear 2.1 ~2.6 50000~60000 605 --- 20 M13E5030
M13E5031   5.0 6~10 Red Clear 1.9 ~2.3 1000 ~ 1800 620 ~ 635 --- 20 M13E5031
M13E5032
  5.0 6~10 Red Clear 1.9 ~2.3 2000 ~ 3000 620 ~ 635 --- 20 M13E5032
M13E5033
  5.0 6~10 Red Clear 1.9 ~2.3 4000 ~ 6000 620 ~ 635 --- 20 M13E5033
M13E5034
  5.0 6~10 Red Clear 1.9 ~2.3 10000 ~ 12000 620 ~ 635 --- 20 M13E5034
M13E5035
  5.0 6~10 Orange Clear 1.9 ~2.3 1800 ~ 3000 610 ~ 620 --- 20 M13E5035
M13E5036
  5.0 6~10 Amber Clear 1.9 ~2.3 1800 ~ 3000 600 ~ 610 --- 20 M13E5036
M13E5037
  5.0 6~10 Yellow Clear 1.9 ~2.3 1000 ~1800 580 ~ 595 --- 20 M13E5037
M13E5038
  5.0 6~10 Yellow Clear 1.9 ~2.3 2000 ~3000 580 ~ 595 --- 20 M13E5038
M13E5039
  5.0 6~10 Yellow Clear 1.9 ~2.3 4000 ~ 6000 580 ~ 595 --- 20 M13E5039
M13E5040
  5.0 6~10 Yellow Clear 1.9 ~2.3 10000 ~ 12000 580 ~ 595 --- 20 M13E5040
M13E5041
  5.0 6~10 Green Clear 1.9 ~2.3 1200 ~ 2000 565 ~ 575 --- 20 M13E5041
M13E5042
  5.0 6~10 Cyan Clear 2.9 ~3.3 10000 ~ 13000 495 ~ 510 --- 20 M13E5042
M13E5043
  5.0 6~10 Green Clear 2.9 ~3.3 5000 ~ 7000 520 ~530 --- 20 M13E5042
M13E5044
  5.0 6~10 Green Clear 2.9 ~3.3 8000 ~ 13000 520 ~530 --- 20 M13E5042
M13E5045
  5.0 6~10 Blue Clear 2.9 ~3.3 2000 ~3000 460 ~ 470 --- 20 M13E5042
M13E5046
  5.0 6~10 Blue Clear 2.9 ~3.3 3500 ~ 5500 460 ~ 470 --- 20 M13E5042
M13E5047
  5.0 6~10 Blue Clear 2.9 ~3.3 6000 ~ 9000 460 ~ 470 --- 20 M13E5042
M13E5048
  5.0 6~10 White Clear 2.9 ~3.3 3000 ~ 4800   --- 20 M13E5042
M13E5049
  5.0 6~10 White Clear 2.9 ~3.3 7000 ~ 9600   --- 20 M13E5042
M13E5050
  5.0 6~10 White Clear 2.9 ~3.3 12000 ~18000   --- 20 M13E5042
M13E5051                     M13E5042
M13E5052                     M13E5042
M13E5053                     M13E5042
M13E5054                     M13E5042
M13E5055                     M13E5042
M13E5056                     M13E5042
M13E5057                     M13E5042
M13E5058                     M13E5042
M13E5059                     M13E5042
M13E5060                     M13E5042
M13E5061                     M13E5042
M13E5062                     M13E5042
M13E5063                     M13E5042
