| Linecard 5,6x3,0mm Serie M11G8xxx | |||||||||||
| Model-No. + Spec. In PDF. | Size | Viewing | Color | Lens Type | Typical Value | If/ mA | |||||
| Forward Voltage (V) Typ. | Luminious Intensity Typ. (Lm) | Wave Length | |||||||||
| (Unit: mm) | Angle | nm Min. or | |||||||||
| (Coordinates) | |||||||||||
|
5,6x3,0 | 120° | Red | Clear | 2,0~2,4 | 150 | M11G8001 | ||||
|
5,6x3,0 | 120° | Blue | Clear | 3,1~3,4 | 150 | M11G8002 | ||||
|
5,6x3,0 | 120° | Green | Clear | 3,1~3,4 | 150 | M11G8003 | ||||
|
5,6x3,0 | 120° | Yellow | Clear | 2,0~2,2 | 150 | M11G8004 | ||||
|
5,6x3,0 | 120° | Purple | Clear | 3,6~3,8 | 150 | M11G8005 | ||||
|
5,6x3,0 | 120° | Pink | Clear | 3,1~3,4 | 150 | M11G8006 | ||||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 2000~2500K | 150 | M11G8007 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 2500~3000K | 150 | M11G8008 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 3000~3500K | 150 | M11G8009 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 3500~4000K | 150 | M11G8010 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 4000~4500K | 150 | M11G8011 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 4500~5000K | 150 | M11G8012 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 5000~5500K | 150 | M11G8013 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 5500~6000K | 150 | M11G8014 | ||
|
5,6x3,0 | 120° | White | Clear | 3,1~3,4 | 45~50lm | 6000~6500K | 150 | M11G8015 | ||
|
|
|||||||||||
