| Linecard Mini PLCC 2 2,0x1,4mm Serie M11F4000 | |||||||||||
| Model-No. + Spec. In PDF. | Size | Viewing | Color | Lens Type | Typical Value | If/ mA | |||||
| Forward Voltage (V) Typ. | Luminious Intensity Typ. (mcd) | Wave Length | |||||||||
| (Unit: mm) | Angle | nm Min. or | |||||||||
| (Coordinates) | |||||||||||
|
2,0x1,4 | 120 | Blue | Clear | 3,4 | 350 | 470 | 20 | M11F4001 | ||
|
2,0x1,4 | 120 | Pure Green | Clear | 3,4 | 250 | 525 | 20 | M11F4002 | ||
|
2,0x1,4 | 120 | Super Yellow Green | Clear | 2,0 | 35 | 573 | 20 | M11F4003 | ||
|
2,0x1,4 | 120 | Super Yellow | Clear | 2,0 | 50 | 589 | 20 | M11F4004 | ||
|
2,0x1,4 | 120 | Hyper Red | Clear | 2,0 | 90 | 624 | 20 | M11F4005 | ||
|
2,0x1,4 | 120 | White | Yellow diffused | 3,4 | 250 | X=0,30/ Y=0,31 | 20 | M11F4006 | ||
|
|
|||||||||||
