Mono Color
Item-No. + Size Viewing Color Lens Type Typical Value Color  If/ mA
Forward  Luminious Wave Length   Temper-
Data Sheet ( Unit: mm ) Angle Voltage Intensity nm or ature
( V ) ( mcd ) (Coordinates) ( K )
M11E6001
  2.0 x 1.25 140 Blue Clear 3.5 ~ 4.3 21 ~ 26 430 --- 20 M11E6001
M11E6002   2.0 x 1.25 140 Blue Clear 3.5 ~ 4.3 30 ~ 50 470 --- 20 M11E6002
M11E6003   2.0 x 1.25 140 Blue Green Clear 3.5 ~ 4.3 36 ~ 62 505 --- 20 M11E6003
M11E6004   2.0 x 1.25 140 Green Clear 2.1 ~ 2.4 6 ~ 10 571 --- 20 M11E6004
M11E6005   2.0 x 1.25 140 Yellow Clear 2.0 ~ 2.4 17 ~ 43 589 --- 20 M11E6005
M11E6006   2.0 x 1.25 140 Yellow Orange Clear 2.0 ~ 2.4 100 ~ 160 605 --- 20 M11E6006
M11E6007   2.0 x 1.25 140 Red Clear 2.0 ~ 2.4 17 ~ 42 624 --- 20 M11E6007
M11E6008   2.0 x 1.25 140 White Clear 3.6 ~ 4.0 100 ~ 160 --- --- 20 M11E6008
M11E6009   2.0 x 1.25 140 Purple Clear 3.6 ~ 4.0 100 ~ 160 --- --- 20 M11E6009
M11E6010
  2.0 x 1.25 120 Red Clear 1.9 ~ 2.4 40 ~ 80 620 ~ 635 --- 20 M11E6010
M11E6011
  2.0 x 1.25 120 Red Clear 1.9 ~ 2.4 80 ~ 100 620 ~ 635 --- 20 M11E6011
M11E6012
  2.0 x 1.25 120 Red Clear 1.9 ~ 2.4 120 ~ 160 620 ~ 635 --- 20 M11E6012
M11E6013
  2.0 x 1.25 120 Yellow Clear 1.9 ~ 2.4 40 ~ 80 580 ~ 595 --- 20 M11E6013
M11E6014
  2.0 x 1.25 120 Yellow Clear 1.9 ~ 2.4 80 ~ 120 580 ~ 595 --- 20 M11E6014
M11E6015
  2.0 x 1.25 120 Yellow Clear 1.9 ~ 2.4 120 ~ 160 580 ~ 595 --- 20 M11E6015
M11E6016
  2.0 x 1.25 120 Green Clear 1.9 ~ 2.4 10 ~ 30 565 ~ 575 --- 20 M11E6016
M11E6017
  2.0 x 1.25 120 Green Clear 1.9 ~ 2.4 40 ~ 80 565 ~ 575 --- 20 M11E6017
M11E6018
  2.0 x 1.25 120 Blue Clear 2.9 ~ 3.5 60 ~ 80 460 ~ 470 --- 20 M11E6018
M11E6019
  2.0 x 1.25 120 Blue Clear 2.9 ~ 3.5 80 ~ 120 460 ~ 470 --- 20 M11E6019
M11E6020
  2.0 x 1.25 120 Green Clear 2.9 ~ 3.5 520 ~ 530 520 ~ 530 --- 20 M11E6020
M11E6021
  2.0 x 1.25 120 Green Clear 2.9 ~ 3.5 520 ~ 530 520 ~ 530 --- 20 M11E6021
M11E6022
  2.0 x 1.25 120 White Clear 2.9 ~ 3.5     --- 20 M11E6022
M11E6023
  2.0 x 1.25 120 White Clear 2.9 ~ 3.5     --- 20 M11E6023
M11E6024
  2.0 x 1.25 120 Warm White Clear 2.9 ~ 3.5     --- 20 M11E6024
M11E6025
  2.0 x 1.25 120 Pink Clear 3.0 ~ 3.6     --- 20 M11E6025
M11E6026                     M11E6026
M11E6027                     M11E6027
M11E6028                     M11E6028
M11E6029                     M11E6029
M11E6030                     M11E6030
M11E6031                     M11E6031
M11E6032                     M11E6032
M11E6033                     M11E6033
M11E6034                     M11E6034
M11E6035                     M11E6035
M11E6036                     M11E6036
M11E6037                     M11E6037
M11E6038                     M11E6038
M11E6039                     M11E6039
M11E6040                     M11E6040
M11E6041                     M11E6041
M11E6042                     M11E6042
