Linecard Serie M11D1xxx | |||||||||||
Model-No. + Spec. In PDF. | Size | Viewing | Color | Lens Type | Typical Value | If/ mA | |||||
Forward Voltage (V) Typ. | Luminious Intensity Typ. (Lm) | Wave Length | |||||||||
(Unit: mm) | Angle °) | nm Min. or | |||||||||
(Coordinates) | |||||||||||
![]()
|
3,5x3,5 | 120 | Royal Blue | Clear | 3,5 | 465 | 250 | M11D1001 | |||
![]()
|
3,5x3,5 | 120 | Blue | Clear | 3,5 | 475 | 250 | M11D1002 | |||
![]()
|
3,5x3,5 | 120 | Green | Clear | 15 | 535 | 250 | M11D1003 | |||
![]()
|
3,5x3,5 | 120 | Amber | Clear | 7,0 | 595 | 250 | M11D1004 | |||
![]()
|
3,5x3,5 | 120 | Orange | Clear | 7,0 | 615 | 250 | M11D1005 | |||
![]()
|
3,5x3,5 | 120 | Red | Clear | 7,0 | 635 | 250 | M11D1006 | |||
![]()
|
3,5x3,5 | 120 | Cool White | Clear | 42 | 7000-9000K | 250 | M11D1007 | |||
![]()
|
3,5x3,5 | 120 | Daylight White | Clear | 42 | 5000-7000K | 250 | M11D1008 | |||
![]()
|
3,5x3,5 | 120 | Nature White | Clear | 35 | 3500-5000K | 250 | M11D1009 | |||
![]()
|
3,5x3,5 | 120 | Warm White | Clear | 35 | 2700-3500K | 250 | M11D1010 | |||
![]() |
|||||||||||
