| Super High Voltage Ceramic Disc Capacitor 6000Volt Range Selection Serie I23002 |
|
|
|
| Item-No.
+ Data Sheet |
Capacitance (pf) |
Capacitance Code |
Material Characteristics |
Cap. Tolerance |
Body Diameter (mm) |
Body Thickness (mm) |
Pitch (mm) |
Wire Diameter (mm) |
|
|
10 |
100 |
SL |
±5% |
8,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
15 |
150 |
SL |
±5% |
8,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
22 |
220 |
SL |
±5% |
8,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
33 |
330 |
SL |
±5% |
8,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
47 |
470 |
SL |
±5% |
9,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
68 |
680 |
SL |
±10% |
11,0 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
100 |
101 |
SL |
±10% |
13,5 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
150 |
151 |
SL |
±10% |
16,0 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
180 |
181 |
SL |
±10% |
16,0 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
100 |
101 |
Y5P |
±10% |
8,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
150 |
151 |
Y5P |
±10% |
8,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
220 |
221 |
Y5P |
±10% |
8,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
330 |
331 |
Y5P |
±10% |
9,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
470 |
471 |
Y5P |
±10% |
9,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
680 |
681 |
Y5P |
±10% |
11,0 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
1000 |
102 |
Y5P |
±10% |
13,5 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
1500 |
152 |
Y5P |
±10% |
16,0 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
2200 |
222 |
Y5P |
±10% |
16,0 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
1000 |
102 |
Y5U |
±20% |
11,0 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
2200 |
222 |
Y5U |
±20% |
14,5 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
1000 |
102 |
Y5V |
±80~-20% |
9,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
1500 |
152 |
Y5V |
±80~-20% |
9,5 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
2200 |
222 |
Y5V |
±80~-20% |
11,0 |
7,0 |
10,0 ±2,0 |
0,65 ±0,05 |
|
|
|
3300 |
332 |
Y5V |
±80~-20% |
12,0 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
4700 |
472 |
Y5V |
±80~-20% |
14,5 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
6800 |
682 |
Y5V |
±80~-20% |
17,5 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
6800 |
682 |
Y5V |
±20% |
16,5 |
5,0 |
12,5 ±2,0 |
0,80 ±0,05 |
|
|
|
10000 |
103 |
Y5V |
±80~-20% |
20,0 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
15000 |
153 |
Y5V |
±80~-20% |
20,0 |
7,0 |
10,0 ±2,0 |
0,80 ±0,05 |
|
|
|
| Please
consult EDCON for another ranges or pitch |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
